Working Height |
15.2m |
---|---|
Platform Height |
13.4m |
Max. Working Outreach |
6.4m |
Platform Size |
1.25 x 0.78 x 1.07m |
Outrigger Footprint |
3.7 x 3.6m |
Overall Width (outriggers extended) |
3.7m |
Overall Width (outriggers stowed) |
1.77m |
Overall Length |
7.45m |
Transport Height |
2.1m |
Platform Capacity (SWL) |
200kg |
Max. Wind Speed |
45kph |
Platform Levelling |
Mechanical |
Turntable Rotation |
540° non-continuous |
Tyres |
185 R15 |
Brakes |
Hydraulic disc |
Insulation Rating |
Nil on standard models |
Hydraulic System |
Proportional electro/hydraulic |
Max. Axle Capacity |
2,000 kg |
Trailer Tongue Weight |
90kg |
Power Source |
Gasoline engine 5.5hp |
Weight |
1,760 kg |
